| P/N | CL-P106-AL09WT-A |
|---|---|
| Compatibility | Intel: LGA 1851/1700/1200/1156/1155/1151/1150 AMD: AM5/AM4/FM2/FM1/AM3+/AM3/AM2+/AM2 |
| Dimensions | 130.9 H* 38 W* 92 L mm |
| Heatsink Material | Aluminum Fins Copper Heatpipes |
| Heatpipe | Φ6mm x 2 pcs |
| Fan Dimension | 92 x 92 x 25 mm(L xW x H) |
| Fan quantity | 1pcs |
| Fan Speed | PWM 800~2000 RPM |
| Rated Voltage | 12V |
| Start Voltage | 6.0 V |
| Rated Current | 0.12 A |
| Power Input | 1.44W |
| Air Flow | 33.12 CFM |
| Static Pressure | 1.02 mm-H2O |
| Acoustical Noise | 24.5 dB-A |
| Life time/Fan Life time | 40,000 hours |
| pin connect | 4 pin PWM |
| Cooling Power | 120 W |
